Rapid, continuous product analysis is critical in all wood manufacturing processes. To maintain consistent product quality, increase yield, maximize efficiency and minimize waste, the Wood Products On-Line Smart Sensor from Process Sensors Corporation (PSC) enables precise analysis of moisture and additional constituents for quick return on investment. With proven performance in all harsh wood production conditions, the MCT460-WP is built to last, simple to install and virtually maintenance free for years of reliable, consistent results.
The MCT460-WP Wood Products On-Line NIR Smart Sensor is used in many wood processes including
|
|
PSC Smart Sensor advantage
The MCT460-WP Wood Products On-Line NIR Smart Sensor comes in multiple configuration options for seamless integration into existing systems. It is easily connected to closed loop control systems or local alarms and eliminates the need for time-consuming and disruptive lab testing. A proprietary temperature-controlled detector enhances stability in arduous environments.
With a standard two year comprehensive warranty and a rugged custom-built cast aluminum enclosure, the MCT460-WP provides years of reliable performance in even the harshest environments. Simultaneous multi-constituent measurement can be made for the following parameters:
|
|
MCT460-WP Wood Products Smart Sensor benefits
The MCT460-WP Wood Products Smart Sensor is designed to provide consistent, reliable performance for quick return on investment. Benefits of all on-line PSC NIR Smart Sensors include:
- High accuracy and repeatability
- Unaffected by relative humidity, changes in product temperature, ambient light and high ambient temperature
- Non-contact, continuous on-line measurement
- Easy calibration, operation & standardization
Simple accessibility & serviceability
The Wood Products On-line NIR Smart Sensor is fully modular with all components easily replaceable in the field within minutes. It is easy to troubleshoot with advanced onboard diagnostics.
Process Sensors’ deep industry knowledge and commitment to our customers’ long-term success ensures you receive the best product for your specific application and full support when you need it during and after installation.
STECIFICATION
MCT 460-WP
| NIR Constiituents | 1, 2 or 3 simultaneously |
| Calibration Codes | 100 |
| Sensor/Product Distance | 8-18 inches (200-450mm) |
| Moisture | +/- 0.1% |
| Resins | +/- 0.2% |
| Wet Basis | Min. 0.1%, Max. 60% |
| Dry Basis | Min. 0.1%, Max. 400% |
| Weight | 19 lbs. (8.6kg) |
| Enclosure | IP67, Cast Aluminum |
| Ambient Temperature | 0-50 °C (32-120˚F); With water or air cooling up to 80°C (160°F) |
| Optional Operator Interface | 5.7 inch Color Touchscreen LCD, 13 User Selectable Languages |
| Optional Bus Interfaces | ProfiNet, ProfiBus, Ethernet IP, Modbus TCP, DeviceNet |
